Megafold has comes to 20 years of solid technical background and is one of the most dynamic, innovative and a market leader in technology & design of operable walls system, Megafold is very reliablewith strong technical superiority and the product is 100% come with uncompromised quality. Megafold always strive for a continuous improvement and is constantly renewing its technologies to uphold its commitment in providing high quality product and through innovative design to meet the ever changing needs and demands of our customers. Our concerted efforts in design & development have gained a strong reputation over the years as a leading manufacturer for operable walls range of products. The technical operations of Megafold are amongst the most advanced system from Germany havingManufactured Locally In Malaysia and all product specification are conformed to the German Standard. Megafold, The Exclusive Designed Acoustic Sound Seal Operable Wall with its technical superiority over other operable walls is certainly a better choice to suit your interior partition needs. Besides, we are offering a very competitive price range at this moment. Megafold uses high quality parts and components with total quality control system that is unequalled by any other manufacturer. Today Megafold has gained a status of Market Leader and most Architects/ Designers are using/ recommending the product because of our uncompromising quality and services. Above all, Megafold also provides Warranty to its product after delivery on installation. Our professional teams of technicians are readily available on after sales service.

Our Product

Technical Specification

MEGAFOLD Acoustic Movable Partition

• Overhead Track System - Specifically casted hardwearing fire resistant heavy duty steel or alumimium track to suit the necessary stacking reequirement. Intersection design shall prevent carrier wheels from dropping into track slot.
• Heavy duty multi-directional roller carrier to facilitate excellent panel movement through curved and straight track section.
• Panel shall be Megafold Super 900 Acoustic Sound Seal Operable Wall/ Partition with unique rapid seal winding mechanism and robust Vertical Seals edge profile ensuring close fit on all panels.
• Panel Configuration - Panels are custom built to suit the specified requirement. Each panel thickness is 100mm maximum; width is 1200mm respectively, which shall conform to the manufacturer's standard. Individual panel is reinforced with welded steel frame and both sides of the outer surface are mounted with 12mm particle board. Internal structure is built with steel mechanism incorporating superior performance Top and Bottom retractable sound seals device. Internal space/ cavities are filled with not less than 60km M³ thick rock wool.
• Megafold Acoustic Sound Seal System - With built in superior retractable Top and Bottom seals consist of extruded aluminium channel anodized with rubber seal laminated and is operated by handle via jacking lock system with spring loaded telescoping rods. Vertical seals of each panel are comprised of deep tongue and grove type extruded aluminium laminated with rubber seal. No Bottom track is required in Magafold Acoustic System Top and Bottom seals do not contact the track and floor during panel movement. When sound seals are compreesed, it gives up to 2000 Newtons per panel pressure and position the panel in solid stability with Top and Bottom seals compressed against track and floor with tight acoustical seals including adjustable telescopic panel.
• Panel Surface - Shall be bare finish 12mm particle boards. However, it can accommodate any decorative designs like wood veener, wall fabrics painting and etc (by others)
• Acoustic Sound Rating of Megafold operable wall partition with high acoustical performance should provide sound attenuation of 46Db to 52DB average.
• Weight - of each panel shall be average 4 kg per sq.ft depending on panel size.
• Application and Operation - shall consist of a series of individual flat wall panels manually operated and permits stacking flexibility at center or remote side stacking.
